Heavy Duty Multi-function modular punching and binding machine (SUPER430M&MF360)
Heavy Duty Multi-function modular punching and binding machine (SUPER430M&MF360)
Heavy Duty Multi-function modular punching and binding machine (SUPER430M&MF360)
Heavy Duty Multi-function modular punching and binding machine (SUPER430M&MF360)
Heavy Duty Multi-function modular punching and binding machine (SUPER430M&MF360)
Heavy Duty Multi-function modular punching and binding machine (SUPER430M&MF360)
Model
SUPER430M&MF360

Item specifics

Model
SUPER430M
width
43mm
Punching thickness
20 -25sheets
punching speed
max 14000sheets/h (depends on operator)
Paper feed
Vertical
Binding machine
3in1 MF360
2:1 wire binding
14.3mm to 38mm
14.3mm to 38mm
4.8mm to 14.3mm
coil binding
4: 1/5: 1 coil binding (6mm to 25mm)
Plastic comb binding
6mm to 51mm

Review

Description

Heavy Duty Multi-function modular punching and binding machine SUPER430M&MF360

PRODUCT DESCRIPTION



 This is a combinaiton machine for all in one punch &bind .With these 2 machines ,you can do any kinds of punching & binding ,plastic punching and binding ;coil spiral punching and binding ;double wire punching and binding ;calendar punching and binding .......

Or if you need any special holes ,we can also make customized .

SUPER430M



The punching machine SUPER430M

Type: punching machine

Mode: electric
Working width: 430mm (17" )
Punching thickness: 20 -25sheets
punching speed: max 14000sheets/h (depends on operator)
Paper feed:  Vertical
Paper ejection:  Automatic
Punching margin: Adjustable.
Punch pins:  Disengageable.
dimension(mm):  590*440*300
Weight: 45kgs

















MF360



Manual wire binding by aluminum handle
For 2: 1 wire binding (14.3mm to 38mm)

Manual wire binding by aluminum handle
For 3: 1 wire binding (4.8mm to 14.3mm )

Electric coil binding by foot pedal
For 4: 1/5: 1 coil binding (6mm to 25mm)

Manual wire binding by aluminum handle

For Plastic comb binding (6mm to 51mm)
All aluminum construction to make the machine durbale and classic
Power: AC110V/240 60/50HZ 200W



Adjustable of wire size guide to select proper wire size









WHEN PUNCH (SUPER430)

WHEN BINDING(MF360)

About our company




Our company ,supu busienss machine ,is specializing in punching and binding machines since 1997 year .Now SUPU is the leader in punching and binding business ,products from office line ,commercial line to itonindustrial line ....

Our principle is " INNOVATION " "QUALITY " "SERVICE " "HONEST " ,We ways give customer good qualtiy products and always consider for customer .We pursuit for good reliationship with cusotmer not only in busienss but also in Freinedship by sincere communication .

Choose us ,choose SUPU ,we promise not let you disappionted since you meet with us .
